EPBR-63H Type AC 10KA 1P+N 6A-63A Residual Current Circuit Breakers with Overcurrent Protection(RCBO)

EPBR-63H Type AC 10KA 1P+N 6A-63A Residual Current Circuit Breakers with Overcurrent Protection(RCBO)

Circuit Breaker

Residual Current Circuit Breaker with Overcurrent Protection, is an electrical safety device that combines the functions of a Residual Current Device (RCD) and a Miniature Circuit Breaker (MCB). It provides protection against earth leakage, overload, and short circuits, making it a versatile safety component for homes and businesses. This single device protects both people from electric shock and wiring from overcurrent faults, and it saves space in electrical switchboards by replacing two separate devices.

Inquire Now Download
Product Description
EPBR-63MH Series  Residual Current Circuit Breakers with Overcurrent Protection
Standard EN/IEC61009-1
Rated conditional short-circuit current(kA) 610
Rated current(A),In 6,10,13,16,20,25,32,40,50,63
Number of poles 1P+N
Rated sensitivity currents(mA),I△n 10,30,100,300
Tripping curve B,C
Rated residual non-operating current 0.5XI△n
Rated impulse withstand voltage Uimp(kV) 4
Rated voltage(V) AC 230/240
Ambient temperature(℃) -25~+40,Max.95%humidity
Residual current off time ≤0.1s
Type of trip Ground fault Electronic
Over current Thermal-magnetic
Electrical endurance 4000
Mechanical endurance 10000
Terminal capacity 10mm²flexible/16mm²rigid
Protection degree IP20
Installation 35mm DIN rail
Certification CE / CB / SAA
