EPR-2-2P 16A 32A 63A 80A 10mA 30mA 100mA 300mA Electromagnetic Residual Current Circuit Breaker Type AC Type A RCD RCCB

EPR-2-2P 16A 32A 63A 80A 10mA 30mA 100mA 300mA Electromagnetic Residual Current Circuit Breaker Type AC Type A RCD RCCB

Circuit Breaker

Residual Current Circuit Breaker, is a safety device that protects against electric shock by detecting current leakage to the ground and disconnecting the circuit when it finds a difference between the live and neutral currents. Different types exist, such as Type AC for general use and Type A for pulsating DC currents, and they are often used with a miniature circuit breaker (MCB) for overload protection.

Inquire Now Download
Product Description
EPR-2 Series          Residual Current Circuit Breaker
Standard EN/IEC61008-1
Rated conditional short-circuit current(kA) 610
Rated current(A),In 16,20,25,32,40,50,63,80
Number of poles 2P(1P+N),4P(3P+N)
Rated sensitivity currents(mA),I△n 10,30,100,300
Rated residual non-operating current 0.5Xl△n
Rated impulse withstand voltage Uimp(kV) 4
Rated voltage(V) 2pole AC 240
4pole AC 415
Ambient temperature(℃) -25~+40,Max.95%humidity
Residual current off--time at I△n ≤0.1s
Rated residual current making
&breaking capacity,I△m		 500A for In=16,25,32,40,50A
630A for In=63A
800A for In=80A
Type of trip Electro-magnetic release
Terminal capacity Cables up to 25mm²
Protection degree IP20
Installation 35mm DIN rail
Certification CE / CB / SAA
